STS2 Total Station
Model STS2 · Reflectorless total station with laser plummet
STS2 is a keypad total station built for crews who prefer physical keys and a clear LCD. It combines a 30× telescope, dual-axis compensation and a laser plummet for quick set-up over a point.
- Range
- 1000–5000 m
- Plummet
- Laser
- Storage
- 32 GB
- 30× telescope, dual-axis compensation
- Laser plummet (optical plummet optional)
- 1000 m reflectorless, 5000 m prism
- 32 GB storage, Bluetooth and USB export
- About 8 h on one lithium battery
- IP54 dust and splash protection
MOQ 1 unitVolume pricing available
1-year warrantyLifetime remote support
Ships in 3–7 daysExpress, air or sea
OEM & ODMLogo, colour, packaging
Overview
Measure up to 1000 m reflectorless and 5000 m with a prism. 32 GB of storage and Bluetooth/USB export make it easy to move jobs to the office.
Horizontal circle temperature compensation and an intelligent calibration routine help keep angles stable through the working day.
Applications
- Construction layout
- Road projects
- Bridge & tower work
- Cadastral
- Teaching
Related
All Total Stations & Theodolites
Construction & infrastructure solutions
Specifications
| Telescope magnification | 30× |
|---|---|
| Range | 1000 m reflectorless / 5000 m prism |
| Compensation | Dual-axis |
| Plummet | Laser (default), optical (optional) |
| Storage | 32 GB |
| Data transfer | Bluetooth, USB |
| Battery | 7.4 V lithium, ≈ 8 h |
| Ingress protection | IP54 |
| Weight | 6 kg |
| Warranty | 1 year |
| Shipping weight | 14 kg |
Need the full datasheet?
We send PDF datasheets, manuals and software details for each batch, together with your quotation.
Request datasheet and priceSpecifications are typical values and may change with product updates. Accuracy depends on satellite geometry, multipath, baseline length and correct set-up.
What is in the box
Typical configuration. Kits are adjusted to your order; tell us what you already own.
- STS2 total station
- Batteries and charger
- Transport case
- Tools and manual
STS2 questions
Not answered here? Ask our engineers.
What are the payment and shipping terms for the STS2?
MOQ is one unit. We accept T/T and quote EXW, FOB Shanghai, CIF or DAP. Stock units usually ship in 3–7 working days by express, air or sea freight, with a one-year warranty.
