P2 Handheld GIS RTK Rover

Model P2 / P2 Plus · 199 g handheld RTK for GIS and personnel tracking

P2 is a 199-gram RTK receiver you can wear, clip to a pole or hold. With 4G on board it connects to CORS directly, and its triple alert – lights, voice and vibration – makes it a practical device for worker positioning, safety zones and asset inspection as well as GIS collection.

Weight: 199 g
RTK: 8 mm + 1 ppm
Network: 4G

199 g, 135 × 70 × 22 mm
RTK 8 mm + 1 ppm horizontal
Built-in 4G for direct CORS connection
60° tilt survey (model-dependent)
Warning lights, voice and vibration alerts
IP67, 4000 mAh, up to 10 h

Get a quotationWhatsApp

MOQ 1 unitVolume pricing available

1-year warrantyLifetime remote support

Ships in 3–7 daysExpress, air or sea

OEM & ODMLogo, colour, packaging

Overview

P2 Plus adds 60° tilt survey for pole work. Both models are IP67 rated, run up to 10 hours on a 4000 mAh battery and charge from any 5 V/2 A USB source.

Horizontal RTK accuracy is 8 mm + 1 ppm, which is survey-grade in a device the size of a phone.

Applications

GIS asset collection
Personnel tracking & safety
Utility inspection
Forestry
Agriculture sampling

All GNSS RTK Receivers
GIS & utility mapping solutions

Specifications

P2 Handheld GIS RTK Rover specifications
GNSS engine	1408 channels, full constellation
RTK accuracy (H)	8 mm + 1 ppm
Work mode	Network RTK rover (CORS account required)
Connectivity	4G, Bluetooth
Tilt survey	60° tilt survey (model-dependent)
Alerts	Lights, voice, vibration
Battery	4000 mAh, up to 10 h; input 5 V / 2 A
Size / weight	135 × 70 × 22 mm, 199 g
Ingress protection	IP67
Operating temperature	−30 °C to +65 °C; −40 °C to +85 °C versions available
Warranty	1 year

Need the full datasheet?

We send PDF datasheets, manuals and software details for each batch, together with your quotation.

Request datasheet and price

Specifications are typical values and may change with product updates. Accuracy depends on satellite geometry, multipath, baseline length and correct set-up.

P2 / P2 Plus questions

Not answered here? Ask our engineers.

What is the difference between P2 and P2 Plus?

P2 Plus adds IMU tilt compensation (up to 60°) for pole surveying; otherwise they share the same GNSS engine, 4G module and alerts.

Can P2 be used for worker safety systems?

Yes. Its alert functions and 4G connection are used for personnel tracking and geofencing. Contact us about data integration and OEM options.

What are the payment and shipping terms for the P2 / P2 Plus?

MOQ is one unit. We accept T/T and quote EXW, FOB Shanghai, CIF or DAP. Stock units usually ship in 3–7 working days by express, air or sea freight, with a one-year warranty.
